WINSAFE UHV-700-AI is a professional 3-in-1 webcam that integrates a 4K EPTZ HD camera, electret microphone and high-performance speakers. It uses a 1/2.8-inch 4k ultra-high-definition CMOS sensor with 8.29 million pixels, which can provide 4K high-quality ultra-clear images with an output frame rate of up to 30 fps. Presenting clear and realistic high-definition video quality, vividly showing the expressions and movements of the characters
WINSAFE UHV-700-AI Webcam adopts 120 super wide-angle distortion-free camera, supports 5x digital zoom and automatic viewfinder function, built-in 2 high-sensitivity 360 microphones and 1 high-performance speaker, providing clear and natural sound quality. With high-quality noise reduction algorithm, the pickup range can reach 5 meters.
The USB-C interface, which integrates power supply and transmission(optional), is simple and convenient, and supports UVC and UAC protocols. It can be applied to personal video applications, collaborative work and other application scenarios. USB-A can expand the pickup range to 8 meters by adding expansion microphones.
Features: - 4K Ultra HD image sensor, can support 4K@30fps high-quality and clear images
- 120° ultra-wide horizontal view angle
- Eptz function, 5X digital zoom with remote control
- Built-in 2 Omnidirectional microphones and speaker, hands-free talk
- USB-A(USB3.0) interface and USB-C(USB3.0), plug and play
- Expansion Mic can be connected with USB-A
- Auto framing function perfectly framing all people in the center of the image
- Protecinng your privacy with the magnetic privacy cover blocking the lens when the webcam is not in use.
- Compatible with most video conferencing applications
Specification: | Model No. | UHV-700-AI |
| Image Sensor | 1/2.8"4K UHD CMOS Sensor |
| Effective Pixels | 8.29 million effective pixels |
| Resolution | 4K(3840×2160) 16:9 |
| AI function | AI face recognition |
| Lens focal length | f=2.02mm |
| Protocol | UVC , UAC |
| Digital Noise Reduction | 2D & 3D DNR |
| S/N Ratio: | >55dB |
| Horizontal viewing angle | 118.8° |
| Video format: | 3840×2160@30fps、1920×1080P@30fps/25fps、1280×720P@30fps/25fps, etc |
| Video compression format | MJPG@30fps; H.264; H.265 YUV |
| White Balance | Auto / Manual |
| Exposure | Auto / Manual |
| BLC | On / Off |
| Auto Framing | On/Off/Sensitive |
| Minimum illumination | 0.1Lux (F1.8, AGC ON) |
| Status Display | LED three-color working status indicator, the appearance is more high-end |
| Special function: | Support EPTZ control |
| Zoom | Fixed focus (support 5x digital zoom) |
| Power consumption | Max 12W |
| Speaker | 1 built-in high-performance speaker |
| Microphone | Built-in 2 microphones |
| Pickup range | 5 meters effective pickup |
| Microphone pointing to | 360° omnidirectional |
| Audio processing functions | Echo Cancellation, Noise Suppression, Automatic Gain |
| Hardware Requirements | 2.4 GHz Intel@Core 2 Duo processor or higher, 2GB RAM or higher,
USB 2.0/USB 3.0 interface (4K requires USB 3.0) |
| Video output interface | USB3.0（Type-C） |
| Expansion microphone interface | USB3.0 A port female socket |
| Power supply | USB powered 12V 1A |
| Supported Operating Systems | Windows 7(1080p at the most), Windows 8.1, Windows 10 ; Mac oS X 10.10 or above, Android, Linux (Require to support UVC.) |
| Operating temperature | ‘-10℃～+50℃ |
| Environment humidity | 20%～90% |
| Size | 210mm×50mm×28mm |
| Product weight | 0.6kg |
| Parts List | Camera*1, USB3.0 data cable*1; Magnetic privacy cover*1; Remote control*1; Manual*1; *1 Power Adapter |
