Feature
※ Effective pixels 2.0 million pixels,1/3 Minimum Illumination CMOS,18x optical zoom
※ Precision motor-driven,keen responsive,smoothly operation,the precision deviation less than 0.1 degree；
※ Support for lightning protection, anti surge, anti surge.；
※ Protection grade: IP66；
※ Support UTC Control Video Transmision can be reach 500M
※ Support PTZ OSD menu
※ 7 PCS infrared light，IR distance 60m；
※ 360°endless pan range and 0°- 90°tilt range, support auto-flip, non-surveillance blind area；
※ Pan control speed 0.6~160°/s, tilt control speed 0.8°~90°/s
※ Support 200 preset, 4 patrols, each patrol can contain up to 32 presets 4 patterns, can totally record up to 10 minus.
※ Support A.B scan、 regional limit;Proportional zoom function, rotation speed can be adjusted automatically according to zoom multiples
※ Support park action, presets/pattern/patrol/pan scan can invoke automatically after a defined time of inactivity (contain the idling condition after the power supply has been turn on)
| Model No. | | CAHC-B1800-P / CAHC-B1800N |
| PTZ Spec. | IR Range | 60M |
| Pan Range Speed | 360° endless; Speed 0.6-160°/S |
| Tilt Range Speed | -15° - 90°, auto flip 180°, speed 0.8° - 90°/s |
| Video | Effective Pixels | 2.0MP 1920(H) x 1080(V) |
| Image Sensor | 1/3"CMOS |
| Min. | Color:0.1Lux@F2, B/W: 0.01Lux@F2 |
| S/N Ratio | Above 50dB(AGC OFF) |
| Lens | Focal Lens | 18X Optical Zoom f=4.7mm - 84.6mm |
| Aperture Range | F1.6 - F2.7 |
| Angle of View | 54.8° - 3.40° |
| Function | White Balance | Automatic |
| Exposure mode | Automatic/Manual |
| Image Mirroring | Support (Pan + Tilt) |
| Image Flip | Support |
| Electronic shutter | 1/30s - 1/10,000s |
| DWDR | Support |
| DNR | 2D-DNR |
| Focus mode | Automatic/Manual |
| Day-Night Mode | Support |
| Digital Zoom | Support |
| Edge illumination Compression | Support |
| Interface | BNC output | HD-TVI(1Vp-p 75Ω), PAL/NTSC, BNC |
| Power and control interface | DC12V/4A, RS485 |
| Others | Power consumption | Max 10W Day-time, Max 30W at night(not include the heat) |
| Working | -20°C - +60°C |
| Protection Grade | TVS3000V lightning protection, surge protection and voltage |
